| Place of Origin: | xiaoshan,zhejiang,china(mainland) |
| Brand Name: | Manguan |
| Certification: | SGS,ISO |
| Model Number: | celukaboard015 |
| Minimum Order Quantity: | 500KGS |
|---|---|
| Price: | negotiable |
| Packaging Details: | pallet |
| Delivery Time: | 10 work days |
| Payment Terms: | Western Union, T/T,Paypal |
| Supply Ability: | 72000pcs per month |
| Material: | PVC | Thickness: | 1-40mm |
|---|---|---|---|
| Size: | 1220*2440mm | Tensile Strength: | 12-20 Mpa |
| Impact Strength: | 8-15kj/m2 | Density: | 0.35~1.0g/cm3 |
| Bending Strength: | 12-18Mpa | Application: | Printing Or Building |
| High Light: | printable foam board,carving foam board |
||
PVC stands for polyvinyl chloride. This plastic is easy and affordable to make and can easily be adapted to a wide variety of applications. PVC is used in a number of specific types of material, including vinyl flooring. Another common use of the product is PVC foam board.
PVC foam is a special form of PVC, but the base material is still manufactured using the same process used to create all PVC products. PVC falls into the category of thermoplastic resins. It is made primarily from a combination of chlorine and carbon. The carbon in the plastic is obtained from oil and gas, but this plastic actually requires less oil and gas than many other types of plastic products.
Specification
Thickness: 1.0-30mm.
Width: 1250mm in max.
Length: Any length.
Density:0.35g/cm3-0.8g/ cm3
Size:1220mmX2440mm,We can also produce special size according to your demands.
Colour:white,grey,black,blue,green,orange,red,puple and any other colours according
to customers' requirements. Also can be ordered according to the RAL color card.
| 1 | Product | PVC Foam Board |
| 2 | Size | 1220mmX2440mm,customized |
| 3 | Thickness | 1.0~30mm |
| 4 | Density | 0.35~0.80g/cm3 |
| 5 | Brand | KUNYI (OEM) |
| 6 | Color | White, Black, Red, Green, Pink, Grey, Blue, Yellow, etc |
| 7 | Executive standard | QB/T 2463.1-1999 |
| 8 | Certificate | ISO9001 |
| 9 | Weldable | Yes |
| 10 | Foam Process | Celuka |
| 11 | Water saturation | <1% |
| 12 | Tensile strength | 12~20MPa |
| 13 | Elongation at break | 15~20% |
| 14 | Vicat softening point | 73~76 °C |
| 15 | Impact strength | 8~15KJ/m2 |
| 16 | Shore Hardness | D 75 |
| 17 | Flexural modulus of elasticity | 800~900MPa |
| 18 | Bending strength | 12~18MPa |
| 19 | Life Span | >50 years |
| 20 | Flame retardance | self-extinguishing less than 5 seconds |
Feature
1. PVC foam board with flame retardant,self-extinguishing,safe to use.
2. Light,tough,rigid with a high impact stregth.
3. Nontoxic and tasteless.
4. Fire-retardant, sound insulation,hot insulation.
5. Water-proof and mould-proof.
6. Color-fast, easy to wash.
7. Can be printed, cut, sawed, nailed, excavated, and welded agglutination.
Application
1 Exhibition cabinet, shelf in supermarket
2 Advertisement Board and Sign Board
3 The advertisement sheet for printing, engraving, cutting, sawing
4 Architectural decoration and upholstery
5 Decoration for partition wall and shopwindows
6 Furniture, Cabinet, Desk, Chair, Wardorbe, Shoecase, Window, Door
